Cryogenic Liquid Argon Storage Tanks: Reliable Solutions from HNJS

Cryogenic Liquid Argon Storage Tanks: Reliable Solutions from HNJS

Introduction

HNJS is a leading manufacturer specializing in pressure vessels, cryogenic solutions, and gas handling equipment.  We hold the esteemed A2 class pressure vessel manufacturing license and D1/D2 class pressure vessel design license, along with GC2/GC3 class pressure pipeline installation permits, all issued by the State Administration of Quality Supervision Inspection and Quarantine.  This accreditation reflects our commitment to quality and safety. Our extensive experience encompasses the production and installation of low, medium, and high-pressure vessels across various classifications. Our comprehensive product portfolio includes cryogenic liquid storage tanks, cryogenic dewar cylinders, cryogenic liquid pumps, specialized cryogenic fluid transfer piping, vaporizers, sophisticated gas pressure regulation systems, and efficient gas filling and dispensing equipment.

Key Features and Advantages of HNJS Cryogenic Liquid Argon Storage Tanks

Our cryogenic liquid argon storage tanks are engineered for optimal performance and longevity, incorporating several key design features:

• Space-Saving Design: The compact footprint of our tanks minimizes space requirements, making them ideal for installations where real estate is a premium.

• Self-Pressurization System:  A fully integrated and sealed system combines the storage tank with a supercharger, allowing for the controlled discharge of liquid or gaseous argon without the need for external energy input. This feature is particularly important as it maintains the inherent purity of the argon during discharge.

• Precise Pressure Control: Equipped with a user-friendly pressure regulating device, our tanks enable precise control over the discharge pressure.  Operators can easily adjust the regulator to meet specific application demands, ensuring a stable and consistent output.

• Versatile Filling and Transfer: The tanks feature dedicated filling ports that facilitate seamless liquid transfer to vaporizers, tankers, or other receiving vessels.

• Superior Insulation Performance: We employ a combination of perlite insulation and specialized sorbents, treated through proprietary processes, to maximize the tank's vacuum lifespan and minimize heat leak. This results in significantly reduced argon boil-off rates. Furthermore, integrated metal thermocouple regulation allows for continuous monitoring of the inter-lining vacuum level, providing valuable operational data.

Technical Specifications

The following parameters outline the standard specifications of our cryogenic liquid argon storage tanks. Customization is available to meet your specific needs:

• Volume Capacity: Ranging from 2 to 200 cubic meters (m³), or as dictated by customer requirements.

• Working Pressure: Adjustable from 0.2 to 1.6 Megapascals (MPa), or tailored to specific application pressures.

• Minimum Design Temperature: -183° Celsius (°C), ensuring safe and reliable operation at cryogenic temperatures.

• Filling Ratio: A maximum filling ratio of 0.95 is maintained to ensure safe operation and prevent over-pressurization.

• Insulation Method: Vacuum powder insulation or high-vacuum multi-layer wrap insulation technologies are employed to minimize heat transfer.

• Applicable Mediums: Suitable for the storage of liquid argon, natural gas, oxygen, nitrogen, ethylene, and other cryogenic fluids.

Packaging and Delivery

To ensure the safe and efficient delivery of your cryogenic storage tank, we offer the following packaging options:

• Standard 20ft and 40ft container shipping.

• Nude packing (protected)

• Seaworthy packing designed to withstand the rigors of international shipping.

• Custom packaging solutions are available upon request.

Delivery Lead Time: Typically 60 days after receipt of advance payment.

HNJS is dedicated to providing reliable and efficient cryogenic liquid argon storage solutions. Contact us today to discuss your specific requirements and discover how our expertise can benefit your operations. We are committed to delivering high-quality products and exceptional customer service.
